Applicable in the production of LDPE, LLDPE, HDPE film (three-layers):Three Layer Co-extrusion Blown Film Machine features higher output, good plasticization, low energy consumption and easy operation. It adopts new high-efficiency low-energy extrusion unit, IBC bubble internal cooling system
Three Layer Co-extrusion Blown Film Machine features higher output, good plasticization, low energy consumption and easy operation. It adopts new high-efficiency low-energy extrusion unit, IBC bubble internal cooling system, ±360° horizontal traction system, photoelectric automatic rectification device, automatic winding and film tension control, and computer screen automatic control system. Compared with similar equipment, it completely solves the problem of film ruffle and winding size.
The produced film has high transparency, puncture resistance, high toughness, good low temperature hot cut property, good composite fastness and anti-curling property. The film has wide barrier properties, preservation, moisture resistance, frost resistance, oxygen barrier, and oil resistance, and can be widely used in light and heavy packaging, such as various fresh fruits, meat products, pickles, fresh milk, liquid beverages, medical supplies, etc..
Main Technical Parameters
|
Type |
SJ45-1200 |
SJ65-1400 |
SJ65-1600 |
|
Diameter of screw |
Ф45(three-layers) |
Ф65(single layer) Ф50(double layer) |
Ф65(three-layers) |
|
Radio of length and diameter |
30:01:00 |
30:01:00 |
30:01:00 |
|
Revolution of screw |
20-150 |
20-150 |
20-150 |
|
Output |
90-120kg/h |
90-140kg/h |
90-140kg/h |
|
Type of mold head |
Rotating |
Rotating |
Rotating |
|
Temperature control |
P10 digit display |
P10 digit display |
P10 digit display |
|
Diameter of mold mouth |
f220 |
f250 |
f300 |
|
Main motor of machine |
15kw(3 units)-6 |
22kw(3 units)-6 |
30kw(3 units)-6 |
|
Power of blower |
5.5kw |
7.5kw |
11kw |
|
Towing motor |
1.5kw frequency VVVF |
1.5kw frequency VVVF |
1.5kw frequency VVVF |
|
Rewind motor |
Torque motor |
||
Applications
Three layer co-extrusion blown film machine applicable in the production of LDPE, LLDPE, HDPE film (three-layers).
